Rulon Sheet Rod

Rulon® is a family of proprietary PTFE materials engineered for High performance self-lubricating applications.
Rulon materials combine high compressive strength, a low coefficient of friction, and excellent abrasion and corrosion resistance.

TriStar is the exclusive North American distributor of Rulon, with the largest US inventory and multiple distribution centers nationwide for immediate delivery

rulon series

Rulon® is the trade name for a family of proprietary PTFE fluoropolymer compounds and other inert ingredients. This family of materials offers the combination of high compressive strengths, low coefficient of friction, and excellent abrasion and corrosion resistance while running without lubrication.

Rulon® is able to withstand temperature extremes of -400°F to over 500°F with and without additional lubricants, ideal In bearing and seal applications. Rulon® products are unique in that they do not cause stick-slip, or erratic low-speed motion. They also withstand a variety of harsh environments such as extreme dryness, cryogenic temperatures, water, steam, and hydrocarbon fuel. Rulon® products primarily are used for mechanical, electrical and chemical applications.


Rulon is the trade name for a family of PTFE plastics produced by Saint Gobain Performance Plastics. Rulon plastics are known for their low coefficient of friction, excellent abrasion resistance, wide range of operating temperatures and chemical inertness. Common applications for Rulon include seals, piston rings, bearings, and electrical insulation

rulon-materials-hero2

History
Rulon, not to be confused with Mulon, was produced by Dixon Industries Corporation in 1952[1] and named after its then President, Robert Rulon-Miller. This first type of Rulon was dubbed "Rulon A" (which was later replaced with type AR). Dixon was then bought by the Furon company. Furon was purchased by Saint-Gobain Performance Plastics



Rulon ® Key Properties

This unique family of materials offers the combination of high compressive strengths, low coefficient of friction, and excellent abrasion and corrosion resistance while running without lubrication. These materials are used in bearing and seal applications at temperature extremes from -400°F to +500°F (-240°C to +260°C) with or without additional lubricants. Rulon ® materials also have the unique property of no "slip stick" --- no erratic motion at low speeds



Common Rulon ® Applications

  • Bushings & Bearings
  • Compressor Applications
  • Insulators
  • Insulators
  • Mixer Applications
  • Pump Applications
  • Textile Industry Applications
  • Thrust Washers
  • Wear Bands



Properties and types

There are many different types of Rulon produced for specific applications. These include:

  • Rulon A, obsolete
  • Rulon AR, maroon ,used for seals & stronger than Rulon LR
  • Rulon LR, maroon , has low deformation characteristics
  • Rulon J, gold,polymer filled for more abrasion resistance and softer mating surface
  • Rulon 641, white ,U.S. Food and Drug Administration compliant
  • Rulon W2, used in fresh water applications
  • Rulon 123, FDA compliant with low and consistent friction characteristics
  • Rulon 488, inorganic filler used for compatibility with most surfaces
  • Rulon 957, green,speckled, bearing grade with noise dampening characteristics
  • Rulon XL, tan,low friction; suitable for aluminium; excellent outgassing characteristics for use in vacuums
  • Rulon F, green, polymer filled with excellent anti-abrasion characteristics
  • Rulon 142, aqua , low deformation material for used in linear bearings and slides
  • Rulon 945, black ,very low deformation characteristics for use in high heat and impact applications
  • Rulon 1045, gold, highly elastic and moderately deformable for use as bearings, rings and seals
  • Rulon 1337, tan, FDA compliant with low coefficient of fricion and excellent chemical resistance
  • Rulon 1410, gold, highly elastic
  • Rulon 1439, white, FDA compliant for use in submerged applications with low wear characteristics

Rulon A has a 1000 fold increase in wear resistance as compared to PTFE However, it machines much like PTFE. It can also be moulded , extruded , skived , stamped , and hot and cold formed. Below is a table of properties pertaining to Rulon AR, but note that the other types of Rulon have similar properties


Properties of Rulon AR
Properties Test procedure used Units (metric) Value (metric)
Specific gravity ASTM D792 n/a 2.22
Hardness ASTM D2240 Shore D 60 - 75
Water absorption ASTM D570 % 0
Tensile strength ASTM D4894 psi (MPa) 2,000 (13.8)
Elongation ASTM D4894 % 175
Deformation under load 1500 psi, 24 hr, RT ASTM D621 % 5.0
Izod impact strength n/a ft-lb/in (J/m) 6.0 (320)
Thermal conductivity ASTM D2214 BTU·in/(hr·Ft2·°F) (W/m·K) 2.3 (0.33)
Operating temperature range n/a °F (°C) -400 to 550 (-240 to 288)
Flammability ASTM D635 in/min (m/s) non-flammable
Maximum pressure (P) n/a psi (MPa) 1,000 (6.9)
Maximum velocity with no pressure (V) n/a ft/min (m/s) 400 (2)
Maximum PV n/a psi x ft/min (MPa x m/s) 10,000 (0.35)
Minimum mating surface hardness n/a RC 35


Rulon 142

Rulon 142


Rulon 488

Rulon 488


Rulon 945

Rulon 945


Rulon 957

Rulon 957


Rulon 1045

Rulon 1045


Rulon 1337

Rulon 1337


Rulon 1410

Rulon 1410


Rulon 1439

Rulon 1439


Rulon AR

Rulon AR


Rulon J

Rulon J


Rulon LR

Rulon LR


Rulon W2

Rulon W2


Rulon XL

Rulon XL


Rulon 123

rulon-materials-icon-123


Rulon 641

rulon-materials-icon-641


Automatic Molding

Custom bearings
Components, near-net

Extrusion

Rods and tubes
Specialty profiles

Hand Molding

Rod, sheet, and tube

Machining

Custom machined parts

Skiving

Tapes and thin sheet

Stamping and forming

Seals
Washers
Bearings and glides
